Singing Rock Snake Brace
Singing Rock · ProfessionalProduct code: W201
SNAKE BRACEAnchor point for through holes, designed to function as a link between the structure and the fall arrest, work positioning, rope access or rescue systems. • intended for through holes whose minimum and maximum diameter corresponds to the type of Snake Brace in relation to the actual thickness of the current …
SNAKE BRACE
Anchor point for through holes, designed to function as a link between the structure and the fall arrest, work positioning, rope access or rescue systems.
Features
- intended for through holes whose minimum and maximum diameter corresponds to the type of Snake Brace in relation to the actual thickness of the current structure
- the opening need not be entirely regular but the minimum diameter must be flat; there must be a minimum space for installation behind the hole
- intended for a single user
- the maximum strength can be used only if the structure in which the anchor hole is located can withstand the load in all directions
- the minimum strength of the construction should be designed according to EN 795 (if not in accordance with EN 795, the load bearing capacity may be reduced)
- Snake Brace can be loaded in any direction only if also allowed by the construction in which is anchored
- can be used only with compatible connectors with locking mechanisms according to EN 362
Standards
- EN 795
- EN 362
Specifications
| Weight | S 300 - 162 g (5.71 oz); M 300 - 395 g (13.93 oz) |
|---|---|
| Material | S - dyneema, alloy, steel; M - PAD, alloy, steel |
| Strength | 18 kN |
| Length | 30, 60, 90, 120 cm |
| Type | Length | Code |
| S 300 | 300 mm | W2018Y030 |
| S 600 | 600 mm | W2018A060 |
| S 900 | 900 mm | W2018R090 |
| S 1200 | 1200 mm | W2018B120 |
| M 300 | 300 mm | W2019Y030 |
| M 600 | 600 mm | W2019A060 |
| M 900 | 900 mm | W2019R090 |
| M 1200 | 1200 mm | W2019B120 |
